Technical item |
Details |
|
PON Interface |
1 G/ EPON port(EPON PX20+ and GPON Class B+ ) |
|
|
Receiving sensitivity: ≤-27dBm |
|
|
Transmitting optical power: 0~+4dBm |
|
|
Transmission distance: 20KM |
|
Wavelength |
TX: 1310nm, RX: 1490nm |
|
Optical Interface |
SC/UPC Connector |
|
LAN Interface |
1 x 10/100/1000Mbps and 1 x 10/100Mbps auto adaptive Ethernet interfaces. Full/Half, RJ45 connector |
|
Wireless |
Compliant with IEEE802.11b/g/n, |
|
Operating frequency: 2.400-2.4835GHz |
|
|
support MIMO, rate up to 300Mbps, |
|
|
2T2R,2 external antenna 5dBi, |
|
|
Support: multiple SSID |
|
|
Channel: Auto |
|
|
Modulation type: DSSS, CCK and OFDM |
|
|
Encoding scheme: BPSK, QPSK, 16QAM and 64QAM |
|
|
LED |
6 LED, For Status of POWER, LOS,PON,LAN1~LAN2,SYS |
|
Push-Button |
3,For Function of Reset,WLAN,WPS |
|
Operating Condition |
Temperature: 0℃~+50℃ |
|
|
Humidity: 10%~90%(non-condensing) |
|
Storing Condition |
Temperature: -30℃~+60℃ |
|
|
Humidity: 10%~90%(non-condensing) |
|
Power Supply |
DC 12V/1A |
|
Power Consumption |
≤6W |
|
Dimension |
155mm×92mm×34mm(L×W×H) |
|
Net Weight |
0.24Kg |
