Items

Unit

Specifications

PON standard.

GPON ITU-T G.984.x, G.988

PON interface

Qty.

4*GPON SFP Ports (Class C+),  Receiving sensitivity: ≤ -30dBm(Saturation Optical -12dBm). Power,Transmitting optical power: +3～+7dBmTransmission distance: 20KM. Max splitting ratio1:128

Speed

Upstream 2.488G

Downstream 1.244G

Wavelength

nm

Tx1310, Rx 1490

Uplink

GE

4*GE(copper Ethernet)

SFP GE

SFP 10GE

2*GE(SFP)/10GE (SFP+) auto-detection

Layer 3

Support static route, RIP v1/v2, OSFP v2, ARP proxy

Management Ports

1*10/100BASE-T out-band port, 1*CONSOLE port

Management Mode

SNMP, Telnet, CLI, WEB

VLAN

Tag / Un-tag，VLAN transmission，QinQ

Operating condition

℃

Operating temp: 0 ~ +50

Storing condition

℃

Storing temp: -40 ~ +85

Humidity

%

5~90(non-condensing)

Power Supply

AC

100～240V, 47/63Hz, (DC:-48V optional)

Power consumption

W

≤45

Dimension

mm

442*220*44（L×W×H）

Net weight

Kg

2.8
