Wavelength(nm)

(800~1700 )

Detector

InGaAs

Measurement Range (dBm)

-70~+10

-50~+26

Uncertainty

+0.2(5%)

Calibrated Wavelength(nm)

850,980,1300,1310,1490,1550, 1625

Resolution(dB)

Linear 0.1% or Non-linear 0.01dBm

Optical Connector

FC/ Universal 2.5mm adapter

(FC,SC,ST interchangeable connector can be optional)

Power Supply

Alkaline Battery(3 AA 1.5V batteries)

Battery Operating Time

240 h with 1.5V Battery(3)

Operating Temperature(oC)

-10 ~ +60

Storage Temperature(oC)

-25 ~ +70

Relative Humidity

0 to 95% (non-condensing)

Dimension(mm)

172x82x33

Weight

300 g
