SFP Transceiver

10G BIDI 11270/1330nm 40KM SFP+ Router With Switch 8 Port Gigabit SFP switch

Product Features

Supports 9.95 to 10.3Gb/s bit rates

Simplex LC Connector

Hot pluggable SFP+ footprint

Uncooled 1270nm DFB transmitter, 1330nm PIN photo-detector

Uncooled 1330nm DFB transmitter, 1270nm PIN photo-detector

Applicable for 10km SMF connection

Low power consumption, < 1W

Digital Diagnostic Monitor Interface

Optical interface compliant to IEEE 802.3ae 10GBASE-LR

Electrical interface compliant to SFF-8431

Operating case temperature:

Commerical:0 to 70 °C    Industrial:-20 to 80 °C

    Product Features

    Supports 9.95 to 10.3Gb/s bit rates

    Simplex LC Connector

    Hot pluggable SFP+ footprint

    Uncooled 1270nm DFB transmitter, 1330nm PIN photo-detector

    Uncooled 1330nm DFB transmitter, 1270nm PIN photo-detector

    Applicable for 10km SMF connection

    Low power consumption, < 1W

    Digital Diagnostic Monitor Interface

    Optical interface compliant to IEEE 802.3ae 10GBASE-LR

    Electrical interface compliant to SFF-8431

    Operating case temperature:

    Commerical:0 to 70 °C    Industrial:-20 to 80 °C



    Applications

    10GBASE-LR at 10.3125Gbps

    10GBASE-LW at 9.953Gbps

    Other optical link



    Product Descriptions

        single mode transceiver is small form factor pluggable module for optical data communications such as 10GBASE-LR/LW defined by IEEE 802.3ae. It is with the SFP+ 20-pin connector to allow hot plug capability. The module is designed for single mode fiber and operates at a nominal wavelength of 1270nm or 1330nm; The transmitter section uses a multiple quantum well DFB, which is class 1 laser compliant according to International Safety Standard IEC-60825.The receiver section uses an integrated InGaAs detector preamplifier (IDP) mounted in an optical header and a limiting post-amplifier IC. The transceiver designs are optimized for high perform -ance and cost effective to supply customers the best solutions for telecommunication.
